5-Ton Mobile Crane

Dual-Side / Synchronous Operation: Features bilateral control handles with synchronous throttle linkage, meaning the engine automatically accelerates or decelerates as you operate the levers for smooth lifting.
Automatic Hook End-Positioning: Saves time before and after transit by securing the hook automatically, preventing damage caused by a swinging hook while driving.
Overwinder Protection: Equipped with a hoisting overwinder safety mechanism that automatically cuts off hook elevation to prevent wire rope fractures.
Chassis Versatility: These units are highly adaptable and are commonly mounted on 4×2 commercial cargo truck chassis (such as Dongfeng, Foton, or Isuzu).

Category: Mobile Crane

Maximum Rated Lifting Capacity: 5,000 kg (5 metric tons at a 2.5-meter working radius)
Maximum Lifting Moment: 10.5 to 12.5 t.m
Maximum Working Radius: 8.5 to 11.0 meters
Maximum Lifting Height: 10.5 to 12.4 meters
Slewing / Rotation Angle: 360° continuous rotation
Crane Self-Weight: Approx. 2,011 kg to 2,170 kg (Crane mechanism only, excluding truck chassis)
Installation Space Required: 900 mm to 1,050 mm (Space needed behind the truck cab to mount the crane)
Hydraulic System Flow: 25 to 32 L/min
Hydraulic System Pressure: 18 to 28 MPa
Recommended Hydraulic Power: 18 kW (24 HP)
